FLANGE COM DN40 1.4404 EPDM

FLANGE COM DN40 1.4404 EPDM - FIT TO EN10357-A TUBE P16 SEMI BRIGHT
Manufacturer:
Alfa Laval
In stock:
Green marker: Product is usually in stock. Yellow marker: Lead time may vary. For time-sensitive orders, please contact us to verify current availability. Note: International shipping may require additional time.
Alsis code:
5044
HS Code:
73072910
Item number:
9612498703
Delivery time:
In Stock
  • Range: Flanges
  • Product Model: Fit to DIN Pressure Flanges
  • Size: DN40
  • Material: 1.4404/EPDM
  • Finish: SB (ID=0.8/OD=1.0)
  • Connection Type: Weld ends
  • Standard: Fit to EN10357-A
  • Design: Complete flange PN16
  • Item Weight: 0.88
Price:
A: 87.00
B: 50.00
C: 4.00 x M8
OD/ID x t: 41.00/38.00 x 1.50
OD1/ID1 x t1: 41.00/38.00 x 1.50
Pressure class PN (Bar): 16
